Guitar Data Sheet

Serial Number: 20-16

Date:  1/30/2020

Guitar Style: OM/   Cutaway

Scale Length: 25.4

Top Wood:  Engelman Spruce

Body Wood:  Figured Walnut

Rosette Styling: Rosewood w/ Small Diamonds

Nut Material:  Bone

Saddle Material/Comp:  Tusq 1/8 inch Compensated

Bridge Material:  Walnut

Bridge Weight:  24.7g

End Graft:  Book matched  Sycamore

Tuning Machines:  Grover 18:1 ratio

Neck Shape:  C shaped

Neck width at Nut: 1 13/16 inch

Bridge String Spacing:  2 ¼ inch

Neck Binding: Click or tap here to enter text.

Body Binding:  Maple with blue/ white veneers; Medium herringbone top purfling

Headstock Binding:  Same

Inlay Materials and Styling:  White MOP

Bracing Material: Red Spruce

Top Bracing Width:  ¼ inch

Scallop Height:  5/8 inch

Back Bracing Pattern:  Live Radial Braced Back

Finish Details:  Epoxy fill, 6 coats lacquer,  Polish

Film Thickness:  .009 inches

Strings: D’Addario Light

Monopole Mobility: Click or tap here to enter text.

Final Frequencies: 98/179/229

Price:$1600.00 with Case
