Guitar Data Sheet

Serial Number: 18-05 Elizabeth’s

Date:  12/01/2018

Guitar Style: OOO-12

Scale Length: 24.9 inches

Top Wood:  Engelman Spruce

Body Wood:  figured Walnut

Rosette Styling: Rosewood with white diamonds

Nut Material:  Bone

Saddle Material/Comp:  1/8 inch bone, non-compensated

Bridge Material:  Ebony

Bridge Weight:  n/a

End Graft:  Book matched Sycamore

Tuning Machines:  Waverly 4070 with Tortoise small Knobs

Neck Shape:  Slotted Martin copy

Neck width at Nut: 1 7/8 inch

Bridge String Spacing:  2.25 inches

Neck Binding: none

Body Binding:  Holly with Black purfling

Headstock Binding:  none

Inlay Materials and Styling:  White MOP

Bracing Material: Red Spruce

Top Bracing Width:  ¼ inch

Scallop Height:  5/8 inch

Back Bracing Pattern:  Martin X

Finish Details:  10 coats lacquer

Film Thickness:  n/a

Strings: D’Addario custom light

Monopole Mobility: 19.3

Final Frequencies: 114/203/227
