John Gorrell Woodworking

Fine Guitars

Guitar Data Sheet

Serial Number: 21-18

Date Started:  3/21/21

Guitar Style:ooo-12

Guitar Total Length: 40 ½ inches

Upper Bout: 10 7/8 inches

Body Thickness at Neck: 4 inches

Body Thickness at End: 4 ½ inches

Waist: 9 ¼ inches

Lower Bout: 15 inches

Scale Length: 24.9 inches

Top Wood:  Adirondack Spruce

Body Wood:  Indian rosewood

Back Strip Detail: Green/Black zipper figure

Rosette Styling: Green, red black with diamond figures

Nut Material:  Bone

Saddle Material/Comp:  Bone, Custom compensated

Bridge Material:  Indian Rosewood

Bridge Weight:  27g

End Graft:  Book matched Sycamore

Tuning Machines:  Waverly chrome butterbean

Neck Shape:  C shaped

Neck width at Nut: 1 7/8 inches

Bridge String Spacing:  2 3/8 inches

Neck Binding: Figured Maple

Body Binding:  Figured Maple with black/white herringbone purfling

Headstock Binding:  none

Inlay Materials and Styling:  Abalone Logo and dots

Bracing Material: Red Spruce

Top Bracing Width:  ¼ inch

Scallop Height:  5/8 inch

Back Bracing Pattern:  Radial

Finish Details:  Epoxy fill, 6 coats Lacquer, Polish

Film Thickness:  .009 inches

Strings: D’Addario custom light, 11-52

Monopole Mobility: 19.5

Final Frequencies: 107/196/234

Price:$1500.00 case included
