Guitar Data Sheet

Serial Number: 21-21

Date Started:  8/17/2021

Guitar Style: Grand Performance, GPH

Guitar Total Length: 40 ¼ inches

Upper Bout: 11 5/8 inches

Body Thickness at Neck: 4 3/8 inches

Body Thickness at End: 5 inches

Waist: 9.5 inches

Lower Bout: 15 7/8 inches

Scale Length: 25.4 inches

Top Wood:  Sitka Spruce

Body Wood:  Figured Black Walnut

Back Strip Detail: Narrow red, maple, black rainbow zipper

Rosette Styling: Multicolor herringbone

Nut Material:  Bone

Saddle Material/Comp:  Bone, manual compensation

Bridge Material:  Indian Rosewood

Bridge Weight:  27.6 g

End Graft:  Book matched Sycamore

Tuning Machines:  Grover Style, Chrome

Neck Shape:  “C” shape

Neck width at Nut: 1 13/16

Bridge String Spacing:  2 3/8 inches

Neck Binding: Maple with red purfling

Body Binding:  Holly with red & multi- color purfling

Headstock Binding:  none

Inlay Materials and Styling:  Logo & dots white MOP

Bracing Material: Red Spruce

Top Bracing Width:  ¼ inches

Scallop Height:  5/8 inches

Back Bracing Pattern:  Radial

Finish Details:  Epoxy Fill, 6 coats lacquer, polish

Film Thickness:  .011 inches

Strings: D’Addario Custom Light 11-52

Monopole Mobility: 16.7

Final Frequencies: 100/183/225

Price:$1325.00 case included
